Address Resolution Protocol (ARP) Service
[Inter-networking layer]

Collaboration diagram for Address Resolution Protocol (ARP) Service:

Data Structures
struct	arp_device
	ARP address map. More...
struct	arp_globals
	ARP global data. More...
struct	arp_proto
	ARP protocol specific data. More...
struct	arp_header
	ARP protocol header. More...
Files
file	arp.c
	ARP module implementation.
file	arp.h
	ARP module.
file	arp_header.h
	ARP protocol header.
file	arp_messages.h
	ARP module messages.
file	arp_module.c
	ARP standalone module implementation.
file	arp_module.h
	ARP module functions.
file	arp_oc.h
	ARP operation codes according to the on-line IANA - Address Resolution Protocol (ARP) Parameters - <http://www.iana.org/assignments/arp-parameters/arp-parameters.xml>, cited January 14 2009.
file	arp_remote.c
	ARP interface implementation for standalone remote modules.
file	arp_interface.h
	ARP module interface.
Defines
#define	NAME "ARP protocol"
	ARP module name.
Typedefs
typedef struct arp_device	arp_device_t
	Type definition of the ARP device specific data.
typedef arp_device_t *	arp_device_ref
	Type definition of the ARP device specific data pointer.
typedef struct arp_globals	arp_globals_t
	Type definition of the ARP global data.
typedef struct arp_proto	arp_proto_t
	Type definition of the ARP protocol specific data.
typedef arp_proto_t *	arp_proto_ref
	Type definition of the ARP protocol specific data pointer.
typedef struct arp_header	arp_header_t
	Type definition of an ARP protocol header.
typedef arp_header_t *	arp_header_ref
	Type definition of an ARP protocol header pointer.
Enumerations
enum	arp_messages { NET_ARP_CLEAN_CACHE = NET_ARP_FIRST, NET_ARP_CLEAR_ADDRESS, NET_ARP_CLEAR_DEVICE, NET_ARP_DEVICE, NET_ARP_TRANSLATE }
	ARP module messages. More...
Functions
void	arp_clear_device (arp_device_ref device)
	Clears the device specific data.
int	arp_proto_create (arp_proto_ref *proto, services_t service, measured_string_ref address)
	Creates new protocol specific data.
int	arp_initialize (async_client_conn_t client_connection)
	Initializes the ARP module.
int	arp_message (ipc_callid_t callid, ipc_call_t call, ipc_call_t answer, int *answer_count)
	Processes the ARP message.
int	module_message (ipc_callid_t callid, ipc_call_t call, ipc_call_t answer, int *answer_count)
	Processes the ARP message.
void	module_print_name (void)
	Prints the module name.
int	module_start (async_client_conn_t client_connection)
	Starts the ARP module.
Variables
arp_globals_t	arp_globals
	ARP global data.
arp_globals_t	arp_globals
	ARP module global data.
Message processing functions

int	arp_device_message (device_id_t device_id, services_t service, services_t protocol, measured_string_ref address)
	Registers the device.
int	arp_mtu_changed_message (device_id_t device_id, size_t mtu)
	Updates the device content length according to the new MTU value.
int	arp_receive_message (device_id_t device_id, packet_t packet)
	Processes the received ARP packet.
measured_string_ref	arp_translate_message (device_id_t device_id, services_t protocol, measured_string_ref target)
	Returns the hardware address for the given protocol address.
ARP module interface
This interface is used by other modules.
int	arp_clean_cache_req (int arp_phone)
	Cleans the cache.
int	arp_clear_address_req (int arp_phone, device_id_t device_id, services_t protocol, measured_string_ref address)
	Clears the given protocol address from the cache.
int	arp_clear_device_req (int arp_phone, device_id_t device_id)
	Clears the device cache.
int	arp_connect_module (services_t service)
	Connects to the ARP module.
int	arp_device_req (int arp_phone, device_id_t device_id, services_t protocol, services_t netif, measured_string_ref address)
	Registers the new device and the requesting protocol service.
task_id_t	arp_task_get_id (void)
	Returns the ARP task identifier.
int	arp_translate_req (int arp_phone, device_id_t device_id, services_t protocol, measured_string_ref address, measured_string_ref translation, char *data)
	Translates the given protocol address to the network interface address.
ARP specific message parameters definitions

#define	ARP_GET_NETIF(call) (services_t) IPC_GET_ARG2(*call)
	Returns the protocol service message parameter.
ARP operation codes definitions

#define	ARPOP_REQUEST 1
	REQUEST operation code.
#define	ARPOP_REPLY 2
	REPLY operation code.
#define	ARPOP_RREQUEST 3
	Reverse request operation code.
#define	ARPOP_RREPLY 4
	Reverse reply operation code.
#define	ARPOP_DRARP_Request 5
	DRARP-Request operation code.
#define	ARPOP_DRARP_Reply 6
	DRARP-Reply operation code.
#define	ARPOP_DRARP_Error 7
	DRARP-Error operation code.
#define	ARPOP_InREQUEST 8
	InARP-Request operation code.
#define	ARPOP_InREPLY 9
	InARP-Reply operation code.
#define	ARPOP_NAK 10
	ARP-NAK operation code.
#define	ARPOP_MARS_Request 11
	MARS-Request operation code.
#define	ARPOP_MARS_Multi 12
	MARS-Multi operation code.
#define	ARPOP_MARS_MServ 13
	MARS-MServ operation code.
#define	ARPOP_MARS_Join 14
	MARS-Join operation code.
#define	ARPOP_MARS_Leave 15
	MARS-Leave operation code.
#define	ARPOP_MARS_NAK 16
	MARS-NAK operation code.
#define	ARPOP_MARS_Unserv 17
	MARS-Unserv operation code.
#define	ARPOP_MARS_SJoin 18
	MARS-SJoin operation code.
#define	ARPOP_MARS_SLeave 19
	MARS-SLeave operation code.
#define	ARPOP_MARS_Grouplist_Request 20
	MARS-Grouplist-Request operation code.
#define	ARPOP_MARS_Grouplist_Reply 21
	MARS-Grouplist-Reply operation code.
#define	ARPOP_MARS_Redirect_Map 22
	MARS-Redirect-Map operation code.
#define	ARPOP_MAPOS_UNARP 23
	MAPOS-UNARP operation code.

Define Documentation

#define ARP_GET_NETIF ( call ) (services_t) IPC_GET_ARG2(*call)

Returns the protocol service message parameter.

Parameters:

[in] call The message call structure.

#define ARPOP_DRARP_Error 7

DRARP-Error operation code.

#define ARPOP_DRARP_Reply 6

DRARP-Reply operation code.

#define ARPOP_DRARP_Request 5

DRARP-Request operation code.

#define ARPOP_InREPLY 9

InARP-Reply operation code.

#define ARPOP_InREQUEST 8

InARP-Request operation code.

#define ARPOP_MAPOS_UNARP 23

MAPOS-UNARP operation code.

#define ARPOP_MARS_Grouplist_Reply 21

MARS-Grouplist-Reply operation code.

#define ARPOP_MARS_Grouplist_Request 20

MARS-Grouplist-Request operation code.

#define ARPOP_MARS_Join 14

MARS-Join operation code.

#define ARPOP_MARS_Leave 15

MARS-Leave operation code.

#define ARPOP_MARS_MServ 13

MARS-MServ operation code.

#define ARPOP_MARS_Multi 12

MARS-Multi operation code.

#define ARPOP_MARS_NAK 16

MARS-NAK operation code.

#define ARPOP_MARS_Redirect_Map 22

MARS-Redirect-Map operation code.

#define ARPOP_MARS_Request 11

MARS-Request operation code.

#define ARPOP_MARS_SJoin 18

MARS-SJoin operation code.

#define ARPOP_MARS_SLeave 19

MARS-SLeave operation code.

#define ARPOP_MARS_Unserv 17

MARS-Unserv operation code.

#define ARPOP_NAK 10

ARP-NAK operation code.

#define ARPOP_REPLY 2

REPLY operation code.

Referenced by arp_receive_message().

#define ARPOP_REQUEST 1

REQUEST operation code.

Referenced by arp_receive_message(), and arp_translate_message().

#define ARPOP_RREPLY 4

Reverse reply operation code.

#define ARPOP_RREQUEST 3

Reverse request operation code.

#define NAME "ARP protocol"

ARP module name.

Typedef Documentation

typedef arp_device_t* arp_device_ref

Type definition of the ARP device specific data pointer.

See also:: arp_device

typedef struct arp_device arp_device_t

Type definition of the ARP device specific data.

See also:: arp_device

typedef struct arp_globals arp_globals_t

Type definition of the ARP global data.

See also:: arp_globals

typedef arp_header_t* arp_header_ref

Type definition of an ARP protocol header pointer.

See also:: arp_header

typedef struct arp_header arp_header_t

Type definition of an ARP protocol header.

See also:: arp_header

typedef arp_proto_t* arp_proto_ref

Type definition of the ARP protocol specific data pointer.

See also:: arp_proto

typedef struct arp_proto arp_proto_t

Type definition of the ARP protocol specific data.

See also:: arp_proto

Enumeration Type Documentation

enum arp_messages

ARP module messages.

Enumerator:

NET_ARP_CLEAN_CACHE	Clean cache message. See also: arp_clean_cache()
NET_ARP_CLEAR_ADDRESS	Clear address cache message. See also: arp_clear_address_msg()
NET_ARP_CLEAR_DEVICE	Clear device cache message. See also: arp_clear_device_req()
NET_ARP_DEVICE	New device message. See also: arp_device_req()
NET_ARP_TRANSLATE	Address translation message. See also: arp_translate_req()

Function Documentation

int arp_clean_cache_req ( int arp_phone )

Cleans the cache.

Parameters:

[in] arp_phone The ARP module phone used for (semi)remote calls.

Returns:: EOK on success.

References NET_ARP_CLEAN_CACHE.

int arp_clear_address_req	(	int	arp_phone,
		device_id_t	device_id,
		services_t	protocol,
		measured_string_ref	address
	)

Clears the given protocol address from the cache.

Parameters:

`[in]`	arp_phone	The ARP module phone used for (semi)remote calls.
`[in]`	device_id	The device identifier.
`[in]`	protocol	The requesting protocol service.
`[in]`	address	The protocol address to be cleared.

Returns:: EOK on success.; ENOENT if the mapping is not found.

References measured_strings_send(), and NET_ARP_CLEAR_ADDRESS.

Here is the call graph for this function:

void arp_clear_device ( arp_device_ref device )

Clears the device specific data.

Parameters:

[in] device The device specific data.

References arp_proto::addr, arp_proto::addr_data, arp_proto::addresses, free, and arp_device::protos.

int arp_clear_device_req	(	int	arp_phone,
		device_id_t	device_id
	)

Clears the device cache.

Parameters:

`[in]`	arp_phone	The ARP module phone used for (semi)remote calls.
`[in]`	device_id	The device identifier.

Returns:: EOK on success.; ENOENT if the device is not found.

References NET_ARP_CLEAR_DEVICE.

int arp_connect_module ( services_t service )

Connects to the ARP module.

Parameters:

service

The ARP module service. Ignored parameter.

Returns:: The ARP module phone on success.; 0 if called by the bundle module.

References connect_to_service().

Here is the call graph for this function:

int arp_device_message	(	device_id_t	device_id,
		services_t	service,
		services_t	protocol,
		measured_string_ref	address
	)

Registers the device.

Creates new device entry in the cache or updates the protocol address if the device with the device identifier and the driver service exists.

Parameters:

`[in]`	device_id	The device identifier.
`[in]`	service	The device driver service.
`[in]`	protocol	The protocol service.
`[in]`	address	The actual device protocol address.

Returns:: EOK on success.; EEXIST if another device with the same device identifier and different driver service exists.; ENOMEM if there is not enough memory left.; Other error codes as defined for the measured_strings_return() function.

References arp_device::addr, arp_proto::addr, arp_device::addr_data, arp_proto::addr_data, arp_proto_create(), arp_device::broadcast_addr, arp_device::broadcast_data, arp_globals::cache, arp_globals::client_connection, arp_device::device_id, ERROR_CODE, ERROR_DECLARE, ERROR_OCCURRED, free, arp_device::hardware, hardware_map(), arp_globals::lock, nil_bind_service, nil_get_addr_req, nil_get_broadcast_addr_req, nil_packet_size_req, arp_device::packet_dimension, arp_device::phone, arp_device::protos, arp_proto::service, arp_device::service, and measured_string::value.

Here is the call graph for this function:

int arp_device_req	(	int	arp_phone,
		device_id_t	device_id,
		services_t	protocol,
		services_t	netif,
		measured_string_ref	address
	)

Registers the new device and the requesting protocol service.

Connects to the network interface layer service. Determines the device broadcast address, its address lengths and packet size.

Parameters:

`[in]`	arp_phone	The ARP module phone used for (semi)remote calls.
`[in]`	device_id	The new device identifier.
`[in]`	protocol	The requesting protocol service.
`[in]`	netif	The underlying device network interface layer service.
`[in]`	address	The local requesting protocol address of the device.

Returns:: EOK on success.; EEXIST if the device is already used.; ENOMEM if there is not enough memory left.; ENOENT if the network interface service is not known.; EREFUSED if the network interface service is not responding.; Other error codes as defined for the nil_packet_get_size() function.; Other error codes as defined for the nil_get_addr() function.; Other error codes as defined for the nil_get_broadcast_addr() function.

References measured_strings_send(), and NET_ARP_DEVICE.

Referenced by ip_netif_initialize().

Here is the call graph for this function:

Here is the caller graph for this function:

int arp_initialize ( async_client_conn_t client_connection )

Initializes the ARP module.

Parameters:

[in] client_connection The client connection processing function. The module skeleton propagates its own one.

Returns:: EOK on success.; ENOMEM if there is not enough memory left.

Referenced by module_start().

Here is the caller graph for this function:

int arp_message	(	ipc_callid_t	callid,
		ipc_call_t *	call,
		ipc_call_t *	answer,
		int *	answer_count
	)

Processes the ARP message.

Parameters:

`[in]`	callid	The message identifier.
`[in]`	call	The message parameters.
`[out]`	answer	The message answer parameters.
`[out]`	answer_count	The last parameter for the actual answer in the answer parameter.

Returns:: EOK on success.; ENOTSUP if the message is not known.

See also:: arp_interface.h; IS_NET_ARP_MESSAGE()

Referenced by module_message().

Here is the caller graph for this function:

int arp_mtu_changed_message	(	device_id_t	device_id,
		size_t	mtu
	)

Updates the device content length according to the new MTU value.

Parameters:

`[in]`	device_id	The device identifier.
`[in]`	mtu	The new mtu value.

Returns:: ENOENT if device is not found.; EOK on success.

References arp_globals::cache, packet_dimension::content, arp_globals::lock, and arp_device::packet_dimension.

int arp_proto_create	(	arp_proto_ref *	proto,
		services_t	service,
		measured_string_ref	address
	)

Creates new protocol specific data.

Allocates and returns the needed memory block as the proto parameter.

Parameters:

`[out]`	proto	The allocated protocol specific data.
`[in]`	service	The protocol module service.
`[in]`	address	The actual protocol device address.

Returns:: EOK on success.; ENOMEM if there is not enough memory left.

References ERROR_CODE, ERROR_DECLARE, ERROR_OCCURRED, free, arp_proto::service, and measured_string::value.

Referenced by arp_device_message().

Here is the caller graph for this function:

int arp_receive_message	(	device_id_t	device_id,
		packet_t	packet
	)

Processes the received ARP packet.

Updates the source hardware address if the source entry exists or the packet is targeted to my protocol address. Responses to the ARP request if the packet is the ARP request and is targeted to my address.

Parameters:

`[in]`	device_id	The source device identifier.
`[in,out]`	packet	The received packet.

Returns:: EOK on success and the packet is no longer needed.; 1 on success and the packet has been reused.; EINVAL if the packet is too small to carry an ARP packet.; EINVAL if the received address lengths differs from the registered values.; ENOENT if the device is not found in the cache.; ENOENT if the protocol for the device is not found in the cache.; ENOMEM if there is not enough memory left.

References arp_device::addr, arp_proto::addr, packet_dimension::addr_len, arp_proto::addresses, ARPOP_REPLY, ARPOP_REQUEST, arp_globals::cache, CONVERT_SIZE, ERROR_DECLARE, ERROR_PROPAGATE, arp_device::hardware, arp_header::hardware, arp_header::hardware_length, htons, measured_string::length, measured_string_create_bulk(), nil_send_msg, ntohs, arp_header::operation, arp_device::packet_dimension, packet_get_data(), packet_get_data_length(), packet_set_addr(), arp_device::phone, arp_header::protocol, arp_header::protocol_length, protocol_unmap(), arp_device::protos, arp_device::service, and measured_string::value.

Here is the call graph for this function:

task_id_t arp_task_get_id ( void )

Returns the ARP task identifier.

Returns:: The current task identifier if called by the bundle module.; 0 if called by the remote module.

measured_string_ref arp_translate_message	(	device_id_t	device_id,
		services_t	protocol,
		measured_string_ref	target
	)

Returns the hardware address for the given protocol address.

Sends the ARP request packet if the hardware address is not found in the cache.

Parameters:

`[in]`	device_id	The device identifier.
`[in]`	protocol	The protocol service.
`[in]`	target	The target protocol address.

Returns:: The hardware address of the target.; NULL if the target parameter is NULL.; NULL if the device is not found.; NULL if the device packet is too small to send a request.; NULL if the hardware address is not found in the cache.

References arp_device::addr, arp_proto::addr, packet_dimension::addr_len, arp_proto::addresses, ARPOP_REQUEST, arp_device::broadcast_addr, arp_globals::cache, packet_dimension::content, CONVERT_SIZE, arp_device::hardware, arp_header::hardware, arp_header::hardware_length, htons, measured_string::length, arp_globals::net_phone, nil_send_msg, arp_header::operation, arp_device::packet_dimension, packet_get_4(), packet_get_id(), packet_set_addr(), packet_suffix(), arp_device::phone, pq_release(), packet_dimension::prefix, arp_header::protocol, arp_header::protocol_length, protocol_map(), arp_device::protos, arp_device::service, packet_dimension::suffix, and measured_string::value.

Here is the call graph for this function:

int arp_translate_req	(	int	arp_phone,
		device_id_t	device_id,
		services_t	protocol,
		measured_string_ref	address,
		measured_string_ref *	translation,
		char **	data
	)

Translates the given protocol address to the network interface address.

Broadcasts the ARP request if the mapping is not found. Allocates and returns the needed memory block as the data parameter.

Parameters:

`[in]`	arp_phone	The ARP module phone used for (semi)remote calls.
`[in]`	device_id	The device identifier.
`[in]`	protocol	The requesting protocol service.
`[in]`	address	The local requesting protocol address.
`[out]`	translation	The translation of the local protocol address.
`[out]`	data	The allocated raw translation data container.

Returns:: EOK on success.; EINVAL if the address parameter is NULL.; EBADMEM if the translation or the data parameters are NULL.; ENOENT if the mapping is not found.

References generic_translate_req(), and NET_ARP_TRANSLATE.

Referenced by ip_send_route().

Here is the call graph for this function:

Here is the caller graph for this function:

int module_message	(	ipc_callid_t	callid,
		ipc_call_t *	call,
		ipc_call_t *	answer,
		int *	answer_count
	)

Processes the ARP message.

Delegates the messages to the netif_message() function.

Processes the module message.

Parameters:

`[in]`	callid	The message identifier.
`[in]`	call	The message parameters.
`[out]`	answer	The message answer parameters.
`[out]`	answer_count	The last parameter for the actual answer in the answer parameter.

Returns:: EOK on success.; Other error codes as defined for the arp_message() function.

Distributes the message to the right bundled module.

Parameters:

`[in]`	callid	The message identifier.
`[in]`	call	The message parameters.
`[out]`	answer	The message answer parameters.
`[out]`	answer_count	The last parameter for the actual answer in the answer parameter.

Returns:: EOK on success.; ENOTSUP if the message is not known.; Other error codes as defined for each bundled module message function.

Parameters:

`[in]`	callid	The message identifier.
`[in]`	call	The message parameters.
`[out]`	answer	The message answer parameters.
`[out]`	answer_count	The last parameter for the actual answer in the answer parameter.

Returns:: EOK on success.; ENOTSUP if the message is not known.; Other error codes as defined for each specific module message function.

References arp_message().

Referenced by client_connection().

Here is the call graph for this function:

Here is the caller graph for this function:

void module_print_name ( void )

Prints the module name.

See also:: NAME

References NAME.

int module_start ( async_client_conn_t client_connection )

Starts the ARP module.

Starts the network interface module.

Starts the networking module.

Initializes the client connection serving function, initializes the module, registers the module service and starts the async manager, processing IPC messages in an infinite loop.

Parameters:

[in] client_connection The client connection processing function. The module skeleton propagates its own one.

Returns:: EOK on successful module termination.; Other error codes as defined for the arp_initialize() function.; Other error codes as defined for the REGISTER_ME() macro function.

Initializes the client connection serving function, initializes the module, registers the module service and starts the async manager, processing IPC messages in an infinite loop.

Parameters:

[in] client_connection The client connection processing function. The module skeleton propagates its own one.

Returns:: EOK on successful module termination.; Other error codes as defined for the net_initialize() function.; Other error codes as defined for the REGISTER_ME() macro function.

Initializes the client connection serving function, initializes the module, registers the module service and starts the async manager, processing IPC messages in an infinite loop.

Parameters:

[in] client_connection The client connection processing function. The module skeleton propagates its own one.
